Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer

I'm Online Chat Now

Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer

Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer
Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer

Large Image :  Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer

Product Details:
Place of Origin: China
Brand Name: OEM
Certification: CE
Model Number: Ball screw Linear Actuator
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs linear actuator
Price: Negotiable
Packaging Details: 2pcs linear actuator per carton box
Delivery Time: 7-10 work days
Payment Terms: T/T, Western Union
Supply Ability: 2000pcs linear actuator monthly

Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer

Description
Voltage: 12V/24V/36V/48V Feedback: Hall Sensor Or Pot
Mounting Requirements: φ13 IP Rating: IP65/IP66
Duty Cycle: 25% Stroke: Customize
Feature: Waterproof, Easy To Install Limit Switches: Inner
High Light:

acme screw linear actuator

,

linear screw drives

12v/24v Brush DC Power-driven Electric Linear Actuators With Potentiometer 300mm stroke for Mobility scooter



R&D continues at sino linear actuator as we develop smaller, powerful, stable and more cost effective linear actuators

for the next generation of automation.



  • Over 10 models to choose from
  • Stroke lengths from 30mm to 1000mm
  • 12V , 24V input options
  • We offer both rod actuators and linear actuators
  • Forces up to 12000N
  • No in-stock, every piece are customized device
  • Phone and email support
  • All products have 1 year warranty





Specification of Ball screw Linear Actuator



Item: Linear actuator

Housing material: Steel

Motor Type: Permanent magnet brushed DC motor

Input voltage: 12V/24V/36V/48V

Drive system type: Gear

Nut material: POM /Brass

Rated load: 7000N

Max stroke: 600mm

Feedback signal: Optional (potentiometer)

Finish: Power Coated

Duty cycle: 25%

Limit switches: Built-in





Load & Speed of linear actuator



linear actuator Load±10%(N) Speed±2(mm/S)
Load 7,000 5,000 4,000 3,000 2,000
Speed 5.5 11 17 22 35





Stroke & Installation length of linear actuator:



Stroke size(in mm) Fully retracted (in mm) Fully extended (in mm)
50 250 300
100 300 400
150 350 500
200 400 600
250 450 700
300 500 800
350 600 950
400 650 1050
450 700 1150
500 750 1250
550 800 1350
600 850 1450



CUSTOM OPTIONS



· Customize force to 2000n (35mm/sec) or 7000n (5.5mm/sec)

· Customize voltage to 24V, 36V or 48V

· Customize stroke length from 25-800mm (1’’-32’’)

· Add Potentiometer or Hall Effect Sensor

· Customize actuator mounting holes

· Customize actuator dimensions

· Customize the wired connector





Linear actuator with limit switch/potentiometer

50≤Stroke<400, L=S+250mm

400≤Stroke<600, L=S+300mm





Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer 0

Picture of the linear actuator with limit switches



Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer 1





Linear actuator without limit switch

50≤Stroke<400, L=S+200mm

400≤Stroke<600, L=S+250mm

Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer 2





Picture of the linear actuator without limit switches

Brush DC Power Linear Motion Slides Ball Screw Driven With Potentiometer 3





How can you find the right linear actuator?



When determining a design for your linear actuator, there are countless factors to take into consideration.

One of the first things you'll need to determine is the viability of standard linear actuator designs for your project.

If standard can't be made to work efficiently, it's time to start looking at custom options.

· Size

· Input voltage

· Load speed

· Load capacity in lbs/N

· Environment

· IP rate

· Production

· Material





Q: What kinds of payment terms are accepted?

A: TT (telegraphic transfer) , Western Union, Private bank account



Q: When the goods can be shipped out after order is placed?

A: Depends on the complex of linear actuator and order quantity, standard sample linear actuator stroke and specifications, range of production is 7 work days, bulk order linear actuator it requires longer time.



WARRANTY OF LINEAR ACTUATOR

We guarantee that all products (LINEAR ACTUATOR) you receive will be brand new, and have been thoroughly tested for defect and performance before being shipped to you. At our company we put our products to the test, stressing their performance in heat, cold, liquid, and under heavy loads and high duty cycles. The specifications listed on our products aren't just approximations; they're backed up by hours and days of testing. We're so confident in our actuators quality, performance, and endurance, that we proudly offer the industry leading 18 month warranty.



All linear actuators produced and sold by our company are covered by our comprehensive 18 month warranty against defect or flaw. If we sell you a product, and it stops working before 18 month pass, we will replace it free of charge. However, the product has to only have been used within its rated parameters and environment conditions.
