|Power Source:||12VDC-48VDC||Feedback:||Potentiometer Or Hall Sensors|
|IP Rating:||66||Duty Cycle:||25%|
|Item Name:||Industrial Linear Actuators / Electric Actuator||Warranty Of Linear Actuator:||1 Year|
|Stroke:||Within 1000mm, CUSTOMIZED LENGTH||Cable Length:||0.4m|
Basic info of linear actuator
* Built-in end-stop
* Robust appearance
* IP65 Protection
* CE Certified
* Limit Switch Integrated
* Max. Load 12000N
* Input Voltage 12V, 24V, 36V, 48VDC
* Signal Feedback Potentiometer or Hall Sensor
Features of linear actuator
Where can use linear actuator:
Various agricultural machinery.
Various equipment that needs to lift up a load: Such as Medical instruments and vehicular installations.
Various constructions used for hanging a load: Such as lightweight hoisting machines.
To be used under undesirable weather conditions: Waterproof, Dustproof.
If you're looking for electric components, a key rating to look for is the IP rating,
you will find specifications indicating IP65, IP66, etc
These show that the linear actuator is suitable for many conditions you will encounter outdoors.
For example, IP65 indicates dust-tight and protected against non-pressurized water jets.
|IP Number||First Digit - SOLIDS||Second Digit - LIQUIDS|
|IP43||Protected from tools and small wires greater than 1 millimeter.||Protected from water spray less than 60 degrees from vertical.|
|IP54||Protected from limited dust ingress.||Protected from water spray from any direction.|
|IP65||Protected from total dust ingress.||Protected from low-pressure water jets from any direction.|
|IP66||Protected from total dust ingress.||Protected from high-pressure water jets from any direction.|
Finished linear actuators
Load & Speed of Industrial Linear Actuator
|Product mode||Max load(N)||Speed (mm/s)|
|HB-DJ805 linear actuator||12000||6.5|
Newton (N) to Pound (lbs)
Linear actuator Bracket
How do I select electrical actuators?
There are many factors to consider when selecting a linear actuator for an application need.
Some of these important parameters are mentioned below:
Application of Industrial Linear Actuators:
You have questions. We have answer!
To best serve you and to identify the most appropriate contact for your needs, please inform us of your requirements on the linear actuator.
For Service, Parts or Warranty questions on the linear actuator, we encourage customers to contact with the sales team.
