linear actuator for snowblower chute, 12v electric actuator 4inch stroke

I'm Online Chat Now

linear actuator for snowblower chute, 12v electric actuator 4inch stroke

linear actuator for snowblower chute, 12v electric actuator 4inch stroke
linear actuator for snowblower chute, 12v electric actuator 4inch stroke
linear actuator for snowblower chute, 12v electric actuator 4inch stroke linear actuator for snowblower chute, 12v electric actuator 4inch stroke linear actuator for snowblower chute, 12v electric actuator 4inch stroke linear actuator for snowblower chute, 12v electric actuator 4inch stroke linear actuator for snowblower chute, 12v electric actuator 4inch stroke

Large Image :  linear actuator for snowblower chute, 12v electric actuator 4inch stroke

Product Details:
Place of Origin: CHINA
Brand Name: OEM
Certification: CE
Model Number: Linear actuator with POT, electric actuator
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs linear actuator
Price: Negotiable
Packaging Details: carton box
Delivery Time: 10-12 work days
Payment Terms: T/T, Western Union
Supply Ability: 2000pcs linear actuator per month

linear actuator for snowblower chute, 12v electric actuator 4inch stroke

Description
Power Source: 12VDC-48VDC Temperature Range: -40°C +65°C
Feedback: Potentiometer Or Without IP Rating: 66
Duty Cycle: 25% Item Name: Industrial Linear Actuators / Electric Actuator
Warranty Of Linear Actuator: 1 Year HS Code: 85013100
Color: Black, Silver Color Stroke: Within 600mm, CUSTOMIZED LENGTH

Dear customer,



Good day,



Lisa Hao comes from China, one of the linear motion manufacturers in China.

Glad to know you are interested in our linear actuators.

We have many linear actuators FYI, glad to share info with you.

There are different linear actuators in our factory.

Could you please share with us your requirements for actuators?

We can quote a price or recommend a similar one to you.

You can find me by WhatsApp: +86 18762658863

Any doubts, please let us know.

Waiting for your reply. ^_^



Best regards,

Lisa Hao

 linear actuator for snowblower chute, 12v electric actuator 4inch stroke 0
The linear actuator is a unique device that allows for the circular movement of electric motors to be converted into an up and down motion.
Some of the most popular applications for linear actuators are in the industrial and manufacturing sectors



Where can use linear actuator:


Various agricultural machinery.
Various equipment that needs to lift up a load: Such as Medical instruments and vehicular installations.
Various constructions used for hanging a load: Such as lightweight hoisting machines.
To be used under undesirable weather conditions: Waterproof, Dustproof.



If you're looking for electric components, a key rating to look for is the IP rating,
you will find specifications indicating IP65, IP66, etc
These show that the linear actuator is suitable for many conditions you will encounter outdoors.
For example, IP65 indicates dust-tight and protected against non-pressurized water jets.



IP Number First Digit - SOLIDS Second Digit - LIQUIDS
IP43 Protected from tools and small wires greater than 1 millimeter. Protected from water spray less than 60 degrees from vertical.
IP54 Protected from limited dust ingress. Protected from water spray from any direction.
IP65 Protected from total dust ingress. Protected from low-pressure water jets from any direction.
IP66 Protected from total dust ingress. Protected from high-pressure water jets from any direction.


Black color linear actuator

linear actuator for snowblower chute, 12v electric actuator 4inch stroke 1



Silver color linear actuator



linear actuator for snowblower chute, 12v electric actuator 4inch stroke 2

Load & Speed of Industrial Linear Actuator

Linear Actuator Stroke ±2(mm) Mounting dimensions±3(mm) Without Feedback
Stroke 50 100 150 200 250 300 350 400 450
Size 155 205 255 305 355 420 470 520 570
Linear Actuator Stroke ±2(mm) Mounting dimensions±3(mm) With Potentiometer
Stroke 50 100 150 200 250 300 350 400 450
Size 185 235 285 335 385 450 500 550 600


Weight of Industrial Linear Actuator

Stroke Retracted Length Extended Length Weight
2'' 6.2'' 8.2'' 1kg
4'' 8.2'' 12.2'' 1kg
6'' 10.2'' 16.2'' 1kg
8'' 12.2'' 20.2'' 1.5kg
10'' 14.2'' 24.2'' 1.5kg
12'' 16.8'' 28.8'' 2kg
14'' 18.8'' 32.8'' 2kg
16'' 20.8'' 36.8'' 2kg
18'' 22.8'' 40.8'' 2.5kg
20'' 25.2'' 45.2'' 2.5kg




 Linear actuator Bracket dimension



linear actuator for snowblower chute, 12v electric actuator 4inch stroke 3

linear actuator for snowblower chute, 12v electric actuator 4inch stroke 4


How do I select electrical actuators?

There are many factors to consider when selecting a linear actuator for an application need.
Some of these important parameters are mentioned below:

  • Stroke length (travel length)
  • Installation length
  • Mounting requirements
  • Feedback
  • Motor voltage
  • Dynamic load
  • Static load
  • Speed

More linear actuators for you choose



linear actuator for snowblower chute, 12v electric actuator 4inch stroke 5

Application of Industrial Linear Actuators:



  • Farming Machine
  • Snow blower
  • Smoke Exhaust Equipment
  • Automatic Door
  • Automation Equipment
  • Auto Solar Panel Tracking System
  • Wheelchair Lifting
  • Electric Lift Bed

linear actuator for snowblower chute, 12v electric actuator 4inch stroke 6

linear actuator for snowblower chute, 12v electric actuator 4inch stroke 7linear actuator for snowblower chute, 12v electric actuator 4inch stroke 8
