Product Details:
|
Power Source: | 12VDC | IP Rating: | 65 |
---|---|---|---|
Duty Cycle: | 25% | Item Name: | Industrial Linear Actuators |
Stroke: | 50mm | Retracted Length: | 155mm |
Feedback: | Without | Load: | 1000N |
Speed: | 7mm/s | Optional: | Different Front Attachments |
Feature: | Waterproof, Outdoor Use | Name: | Compact Linear Actuator |
Highlight: | aerospace linear actuator,industrial belt driven linear actuators |
The linear actuator is a unique device that allows for the circular movement of electric motors to be converted into an up and down motion. Some of the most popular applications for linear actuators are in the industrial and manufacturing sectors
Why do we choose to use a linear actuator?
It is easy to pull, push, adjust, lift or tilt objects that are hard to reach or the heavy objects. Furthermore, using electric linear actuators is beneficial because the electrical current is transmitted easily to actuators since cabling is cost-effective as compared to piping. More so, the electricity utilized is also cost-effective and efficient. Energy is also distributed softly and modestly to the motor.
Specification of Industrial Linear Actuator:
Linear actuator | trapezoid screw rod |
Power supply | 24VDC /12VDC |
Rated Load | 1200N |
Stroke length | Optional range 50mm~600mm |
Standard speed | 5mm/s~60mm/s |
Maximum installation | L=Stroke S+105mm (50-299mm) L=Stroke S+140mm (300-499mm) L=Stroke S+170mm (500-600mm) |
Environmental temperature | -35℃~65℃ |
Using frequency | 25% |
Protection level | IP65 |
Load & Speed of Industrial Linear Actuator
Linear Actuator | Stroke ±2(mm) | Mounting dimensions±3(mm) | Without Feedback | ||||||
Stroke | 50 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 |
Size | 155 | 205 | 255 | 305 | 355 | 420 | 470 | 520 | 570 |
Linear Actuator | Stroke ±2(mm) | Mounting dimensions±3(mm) | With Potentiometer | ||||||
Stroke | 50 | 100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 |
Size | 185 | 235 | 285 | 335 | 385 | 450 | 500 | 550 | 600 |
Newton (N) to Pound (lbs)
Newton | 1200N | 1000N | 800N | 500N | 200N | 100N |
LBS | 264 | 220 | 176 | 110 | 44 | 22 |
How do I select electrical actuators?
There are many factors to consider when selecting a linear actuator for an application need.
Some of these important parameters are mentioned below:
Application of Industrial Linear Actuator:
Q: What kinds of payment terms are accepted?
A: TT (telegraphic transfer), Western Union, Private bank account
Q: When the goods can be shipped out after an order is placed?
A: Depends on the complexity of linear actuator and order quantity, standard sample linear actuator stroke and specifications,
range of production is 7 workdays, bulk order linear actuator it requires a longer time.
Q: Can you produce a linear actuator as per the samples?
A: Our engineers will evaluate whether we can do it or not,
If yes, we will build the molds and fixtures of the linear actuator for your confirmation.
If not, we will inform you of the result, we may recommend the supplier who can meet your requirements on linear actuator.
Q: May I know the warranty of your linear actuators?
A: For mini size linear actuators, warranty: 12 months
For big size linear actuators, warranty: 15 months
Q: We are interested in being your distributor in our local.
Could you please let me know how can we deal with your linear actuators and your requirements on us?
A: We are looking forward to being your partner in linear motion field, please contact with our sales team, they will inform you more details.
