Product Details:
Place of Origin: China
Brand Name: OEM
Certification: CE
Model Number: Lead screw linear actuator
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs linear actuator
Price: Negotiable
Packaging Details: 2pcs linear actuator per carton box
Delivery Time: 7-10 work days
Payment Terms: T/T, Western Union
Supply Ability: 2000pcs linear actuator monthly

Linear Actuator 12v dc 350mm travel length for AGV, ball screw electric actuator price

Description
Item Name: Lead Screw Linear Actuator, Ball Screw Linear Actuator Screw Type: ACME, Ball Screw
Operational Temperature: -40°C/65°C Limit Switches: Inner, Or Signal Output
IP Rating: IP66 Warranty: 1 Year
HS Code: 85013100 Material Of Nut: Brass
Voltage: 12V, 24V, 36V, 48V Duty Cycle: 25%





The benefits of using the ball screw linear actuator



- Improves speed, force
- Longer and predictable life cycle
- Requires less motor power
- Greater accuracy
- High efficiency (low friction)



Linear Actuator 12v dc 350mm travel length for AGV, ball screw electric actuator price



Because of the COVID-19, many governments encourage the Intelligent Plant, which requires higher precision machines.

Now more and more smart machine manufacturers consider using ball screw linear actuator because it has higher precision and faster speeds.

We can customize different strokes of ball screw actuators, also can do brushless dc motor actuators.

Kindly inform us of your requirements, then we will match the suitable linear actuator for you.

There are different brands and different models of linear actuators in the market.

Choose the right one with the goods price, the most important part is to meet your requirement.






Specification of lead screw linear actuator





Model High force linear actuators
Max. stroke 1000MM
Max. Static load 12000N
Max. Dynamic load 12000N
Operation Speed 6.5 mm/sec/12000N
Input Signal 3.3VDC, 5VDC
Position Detection Hall sensor(s)/ Potentiometer
Motor Brushed DC motor
Degree of Protection IP66
Screw Type Trapezoidal screw
Power Input 24V/12VDC
Self-locking ability NO
Operating temperature -40℃~65℃
Safety nut NO
Optional 1 Cable length
Optional 2 Feedback (POT /hall sensor)
Optional 3 Installation size


L.min means the length when linear actuator 100% fully retracts, meanwhile,
it will touch the tail limited switch, stop automatically, very safe.

Stroke means the movement length of linear actuator.

L.max means the length when linear actuator 100% fully extends, meanwhile,
it will touch the head limited switch, stop automatically, very safe.

Installation size of linear actuator
50≤Stroke≤300, L=S+200mm
300<Stroke≤600, L=S+250mm

For example:  linear actuator, 200mm stroke, 400mm mounting length

Linear Actuator 12v dc 350mm travel length for AGV, ball screw electric actuator price 0

Linear Actuator 12v dc 350mm travel length for AGV, ball screw electric actuator price 1



Our test lab

Linear Actuator 12v dc 350mm travel length for AGV, ball screw electric actuator price 2

Load & Speed of linear actuator



Product mode Max load(N) Speed (mm/s)
 linear actuator 12000 6.5
10000 13
7000 17
6500 20
5000 25
3200 38



Advantages of linear actuator

  • Compact size
  • High waterproof feature
  • Good price



Applications of Linear actuators



· Robotic Vehicles

· Automatic Guidance Vehicles

· Camper

· Led car, arrow board trail

· Door Openers

· Floor Cleaning Equipment

· Lawn Mover

· Snowplow

· Boat

· Solar tracker system

· Wheelchairs

· Harvesting machine

· Construction machine



See below pictures of real applications of linear actuator

Linear Actuator 12v dc 350mm travel length for AGV, ball screw electric actuator price 3Linear Actuator 12v dc 350mm travel length for AGV, ball screw electric actuator price 4

How can you find the right linear actuator?

When determining a design for your linear actuator, there are countless factors to take into consideration.
One of the first things you'll need to determine is the viability of standard linear actuator designs for your project.
If standard can't be made to work efficiently, it's time to start looking at custom options.

· Size

· Input voltage

· Load speed

· Load capacity in lbs/N

· Environment

· IP rate

· Production

· Material




Our main goal is to satisfy and exceed the expectations of our clients.
We have the capabilities to meet low and high product volume requirements.
